Gen 3 - ATN Night Shadow 3 Night Binoculars

Description

The ATN Night Shadow 3 comes standard with our cutting edge "Smart" technology. This technology consists of a computerized proximity sensor, digital controls and a long-range Infrared Illuminator. The proximity sensor will automatically turn the unit on and off when it is brought to the viewing position. This helps to save your battery life and the life of the unit itself. The digital controls allow you to activate all of the features of the ATN Night Shadow 3 with an easy push of a button. We also built a powerful Infrared Illuminator into the
Night Vision Scope . This allows you to see even in total darkness with outstanding clarity.

It is dark. You can barely see your hand in front of your face. You bring your ATN Night Shadow 3 Night Vision Device up to your eyes and turn it on. Suddenly, in green-hued clarity, the entire scene is like a day.

For Camping, Boating, Nature study or Law Enforcement there is simply no better Night Vision Device on the market.

FEATURES

• SMART Technology featuring
• Automatic on/off proximity sensor
• Easy-to-use digital controls
• Multi-coated all-glass optics
• Super fast 5x objective lens
• Built-in adjustable beam Long Range infrared illuminator
• Water and fog resistant
• Camera adaptable
• Limited Two-Year Warranty

Specification

Total Darkness IR System Yes
"SMART" Technology Yes
Multi-Purpose System No
IIT Generation 3
Photocathode Type GaAs
Resolution 64 lp/mm
Signal to Noise Ratio 22 Typical
Figure of Merit 1600 Typical
MTTF - Mean Time Before Failure 10,000 hours
Magnification 5x
Lens System F1.7, 90 mm
Proshield Lens Coating Yes
FOV 9°
Range of Focus 2.5 m to infinity
Diopter Adjustment -5 to +5
Controls Digital
Automatic Brightness Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (focusing)
IR Indicator Yes (LED indicator)
Low Battery Indicator Yes (LED indicator)
Power Supply 2 x 3 V CR123A type battery
Battery Life 50 hrs
Environmental Rating Weather resistant
MIL-STD-810 No
Operating Temperature -40 to +50 °C
Storage Temperature -50 to +70 °C
Dimensions 225 x 122 x 78 mm
9" x 5" x 3"
Weight 1.2 kg / 2.5 lbs
Warranty 2 years

Tube Specifications

HIGH QUALITY 3 GEN IMAGE INTENSIFIER TUBE
DESCRIPTION Standard
GENERATION 3
PHOTOCATHODE TYPE GaAs
RESOLUTION, lp/mm* 64
SIGNAL TO NOISE RATIO* 22 Typical
FIGURE OF MERIT 1600 Typical
MTTF - MEAN TIME BEFORE FAILURE, hours 10,000
EXPORT N/A for Export
* Specifications are provided for informational purposes only. Actual values may vary
